Herbert 14/45 Turret Lathe 1230mm x 2300mm

Out of Stock - Click Here
Request Quote

    WhatsApp

    Description

    Herbert 14/45 Turret Lathe 1230mm x 2300mm

    Swing over bed 1230mm (48.5″)
    Swing over cross slide 815mm (32″)
    Maximum distance between chuck and turret face2300mm (90.5″)
    Spindle speeds 3 -360rpm
    Spindle bore 210mm (8.25″)
    4 jaw chuck 1065mm dia. (42″)
    Main motor 50hp

    Machine Data:

    Serial number 5-2775

    Equipped with:

    Taper turning att.
    2 x adjustable knee tool holders
    3 x boring bar holders
    4 way indexing tool post
    Coolant pump and piping
