Haas VF-3YT/50 Vertical Machining Centre (2014)

Out of Stock - Click Here

Description

X Axis 40 ” 1016 mm
Y Axis 26 ” 660mm
Z Axis 25 ” 635 mm
Spindle Nose to Table (~ max) 29 ” 737 mm
Spindle Nose to Table (~ min) 4 ” 102 mm

Table
Length 48 ” 1219 mm
Width 18 ” 457 mm
T-Slot Width 5/8 ” 16 mm
T-Slot Center Distance 3.15 ” 80.0 mm
Number of Std T-Slots 5 5
Max Weight on Table 1587kg

Spindle
Max Rating 30 hp 22.4 kW
Max Speed 8100 rpm 8100 rpm
Taper BT 50
Bearing Lubrication Air/Oil Injection Air/Oil Injection
Cooling Liquid Cooled Liquid Cooled

Feedrate
Rapids on X 1000 in/min 25.4 m/min
Rapids on Y 1000 in/min 25.4 m/min
Rapids on Z 1000 in/min 25.4 m/min
Max Cutting 650 in/min 16.5 m/min

Tool Changer
Capacity 30
Max Tool Diameter (full) 3.5 ” / 89 mm
Max Tool Weight 5.4 kg
Tool-to-Tool (avg) 4.2 sec
Chip-to-Chip (avg) 4.5 sec

Complete with:

Renishaw WIPS probing package
Thru spindle coolant,
30ATC tool changer
Extended Y axis (660mm travel in Y )
30HP
BT50 Spindle

Machine Data

Serial Number 1110608
Date of MFG 02/2014
Model VF-3YT/50
