Description
Herbert Model 14/45 Long Bed Combination Turret Lathe
Swing over bed 1230mm (48.5″)
Swing over cross slide 815mm (32″)
Maximum distance between chuck and turret face 2800mm (99″)
Spindle speeds 3 -360rpm
Spindle bore 210mm (8.25″)
4 jaw chuck 1065mm dia. (42″)
Main motor 50hp
Equipped with:
2 x adjustable knee tool holders
2 x boring bars/holders
Rapid travel to saddle and Turret
4 way indexing tool post
Three point roller steady
Coolant pump and piping
