Description
Victor V Turn 26 CNC Lathe
Swing over bed 520 mm
Swing over cross-slide 350 mm
Distance centre tot centre 1130 mm
Max longitudinal travel Z-axis 1090 mm
Max cross travel X-axis 240 mm
Spindle cone A2-8
Dia of spindle bore 87 mm
Power on the spindle 15/20 HP
Number of speeds 3500 rpm
Fanuc OT Control
3 Jaw Power Chuck
Tailstock
10 Station Turret
Swarf Conveyor
Year of Manufacture 1995
