LUMSDEN 96ML Rotary Table Surface Grinder

Description

LUMSDEN 96ML Rotary Table Surface Grinder
Segmental wheel diameter 54″ (1371 mm)
Segments per set 18
Table diameter & grinding capacity 100″ (2540 mm)
Magnetic table dia. 100″ (2540 mm)
Max. height of wheel to table 30 ¼” (768 mm)
Min. height of wheel to table 6 ¼” (159 mm)
Max. height of wheel to magnetic table 24″ (610 mm)
Spindle speed 280 rpm
Table speeds 6 2/3 & 2¼
Automatic feed
Power elevation
Spindle motor 140 hp
Floor space 17’ 7″ x 15’ 2″ (5360 mm x 4623 mm)
Total weight 38 ton (38600 kg)
